• Isolated withstand voltage of 2000Vrms
• Data rate: DC to 150Mbps
• Supply voltage: 2.5V to 5.5V
• High CMTI: 200kV/us
• Chip-level ESD: HBM: ±6kV
• Enhanced system level ESD, EFT, surge immunity
• Output low level by default
• Surge voltage: 7kV
• Low power consumption: 1mA/ch (1Mbps)
• Low power consumption: Propagation delay:<10ns
• Operating temperature: -40℃〜 125°C
• RoHS compliant package: DFN8
• VDE qualified: DIN EN 60112 (VDE 0303-11)
• Industrial automation system
• Isolated SPI, RS232, RS485
• Universal Multi-Channel Isolator
• Motor control
