• Up to 8000Vrms insulation voltage
• VDE Reinforced Isolation Qualification
• Data rate DC of up to 150Mbps
• High CMTI: ±250kV/μs
• Chip-level ESD: HBM: ±8kV
• Enhanced ESD, EFT, surge protection at system level
• Low propagation delay typical <15ns
• Low power consumption: 1.5mA/ch (1 Mbps)
• Operation temperature: -40℃~125℃
• AEC-Q100 qualified
• RoHS compliant package: SOP16(300mil), SSOP16, SOP16(600mil)
• UL1577 qualified: 8kVrms for 1 min.
• CQC qualified: Conform to GB4943.1-2022
• CSA qualified: Components conform to 5A
• VDE qualified: DIN EN IEC 60747-17 (VDE 0884-17)
• New energy vehicles
• Industrial automation system
• Isolated SPI, RS232, RS485
• Universal Multi-Channel Isolator
• Motor control
