• Working environment temperature: - 40 ℃ ~ 150 ℃
• Wide programmable sensitivity range: 0.5 ~ 15 mV/G
• High precision, low temperature drift
• Sensitivity error <±2% over the whole temperature range
• Zero drift <±10 mV in the whole temperature range
• Industry-leading noise performance
• High bandwidth and fast response
• 3dB 240kHz bandwidth model, response time 2.2μs
• Industry leading ESD performance
• HBM: ±8kV
• CDM: ±2kV
• 1 mm, TO94 package and a variety of pin bent form
• Support proportional output or fixed output
• Over-current protection, users can configure over-current protection output threshold for the current range of 50% to 200%
• Different models the optional power supply, 3.3V or 5V single power supply work
• Comply with RoHS standard packaging
• Current module
